Description
The 140mm Double Bearing Sliding Gate Wheel is purpose-built for demanding sliding gate applications where strength, stability, and longevity are critical. Manufactured in Italy using precision-machined C45 steel, this wheel delivers reliable performance under heavy loads while maintaining smooth, consistent gate movement.
Featuring a bolt-through configuration, the wheel mounts directly to the underside of the gate frame, simplifying installation and ensuring secure alignment on Angular ‘V’ groove tracks. Twin sealed 6203 2RS bearings reduce rolling resistance and protect against dust and moisture, contributing to extended service life and quiet operation.
A gold galvanised coating provides enhanced corrosion resistance, making this wheel suitable for outdoor environments and high-use installations. Independently tested to withstand up to 1.5 million operating cycles at full load, it is a dependable choice for professional gate fabricators and industrial applications alike.
Supplied complete with an M14×70mm bolt, spacers, and nut, this wheel is ready for installation straight out of the box.
Key Features
•140mm diameter double bearing sliding gate wheel
•Bolt-through design with M14×70mm fixing hardware included
•Compatible with Angular ‘V’ groove sliding gate tracks
•Twin 6203 2RS sealed bearings for smooth, low-maintenance operation
•High load capacity rated up to 510 kg per wheel
•Precision-machined C45 steel construction
•Gold galvanised finish for superior corrosion protection
•Tested to 1.5 million cycles under full load conditions
